MRocky-150/45AI Intelligent Auto Twin Rockwell Hardness Tester

Product Feature
●MRocky-150/45AI fully automatic Rockwell hardness tester complies with the ASTM E18
Rockwell hardness testing method for metallic materials, and has the characteristics of high
automation, high testing accuracy, and high testing efficiency.
●With just one click operation, the test results can be obtained. It is a model developed to
achieve large-scale hardness measurement of workpieces;
●Adopting a cantilever structure with an automatic rising and falling indentor, this
structure achieves full automation of hardness measurement;
●Equipped with a control lever, it can quickly drive the servo motor to adjust the testing
space, improving testing efficiency;
●Touch screen display and operation, equipped with dynamic curve graphs, real-time
monitoring of the operation status of force sensors and displacement sensors, very intuitive.
●The large test stage is convenient for testing large workpieces and can work together
with any brand of robotic arms and automation equipment to form an online system
Hardness testing and complete unmanned testing.
●Transfer data to the computer via USB, Bluetooth, RS232 or other transmission methods,
and connect to dedicated hardness management software for data management

Product Application
●Rockwell hardness: determination of the Rockwell hardness of black metals, non-ferrous
metals, and non-metallic materials; Rockwell hardness applicable to heat treated materials
such as quenching and tempering ,Especially suitable for precision testing of parallel planes.
The V-shaped test bench can be used for precise testing of cylinders.
●Surface Rockwell: Determination of black metals, alloy steels, hard alloys, and metal
surface treatments (carburization, nitriding, electroplating coatings).
●Plastic Rockwell (optional): Rockwell hardness of plastics, composite materials, various
friction materials, as well as soft metal and non-metallic soft materials.Suitable for use in
production lines, workshop laboratories, physical and chemical laboratories, and other
Places.

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Description

Technical Specification

Product Name	Intelligent Auto Twin Rockwell Hardness Tester
Model Number	MRocky-150/45AI
Test Force	Rockwell：60kg，100kg，150kg
	Superficial Rockwell：15kg，30kg，45kg
Test Force Precision	±1%
Test Range	Rockwell：20-88HRA，20-100HRB，20-70HRC Superficial Rockwell：70-91HR15N，42-80HR30N，20-70HR45N, 73-93HR15T，43-82HR30T，12-72HR45T
Indentor	Diamond Rockwell	ф1.588mm Ball
Test Space	Test Height：300mm（also customized）
	Test Throat：190mm（also customized）
Dwelling Time	Initial Test Force:0.1-50sec , Total Test Force:0.1-50sec
Operation	Machine Head Auto Lifting Up and Down, Position can be set, One-key Testing Process
Display	8 inch High Resolution Touch Screen, Menu Program, Hardness Value Display, Parameters Setting, Data Statistic, Save etc.
Hardness Resolution	0.01HR
Hardness Scale	HRA,HRD,HRC,HRF,HRB,HRG,HRH,HRE,HRK,HRL, HRM,HRP,HRR, HRS,HRV,HR15N,HR30N,HR45N, HR15T,HR30T,HR45T,HR15W, HR30W,HR45W,HR15X, HR30X,HR45X,HR15Y,HR30Y,HR45Y
Conversion Scale	According to ASTM E140
Data Statistic	Testing frequency, average value, maximum value, minimum value, repeatability, setting upper and lower limits for hardness values, with warning function, etc
Data Output	USB，RS232
Power	AC110V/220V，50Hz
Executive	ISO6508，ASTME18，JISZ2245，GB/T230.2

Standard Delivery

Item	Qty	Item	Qty
Machine Mainframe	1 pc	Connecting Line	1 pc
1/16”Ball Indenter	1 pc	Anti-dust Cover	1 pc
60-70 HRC Block	1 pc	Diamond Rockwell Indentor	1 pc
40-50 HRC Block	1 pc	Large Test Stage	1 pc
90-95 HRB Block	1 pc	20-30 HRC Block	1 pc
80-90 HRA Block	1 pc	Testing Software	1 set
Power Line	1 pc	Documents	1 Copy
