uRocky-150/45A Digital Twin Rockwell Hardness Tester

Product Feature：

● Test Anvil automatic lifting, without manual rotation of hand-wheel.

● Press the start button, the test anvil rises automatically,test sample will be

loaded and unloaded automatically, and the hardness value will be displayed

automatically.

● Closed loop control system, high precision load cell .

● 8'' touch screen for user directly select the hardness scale and test force and

displays hardness value, conversion scale, test force, dwell time, etc.

● With all kinds of rockwell hardness scales HRA HRB HRC etc and high

resolution 0.1HR.

● Automatic correction of high, medium and low hardness numbers.Automatic

correction of load, with the force accuracy increased by dynamometer.

● Automatically apply the initial test force and main test force.

● Automatic loading- Dwell - Unloading, automatic display hardness value.

● Curve display: test force, displacement depth change curve, real-time test

force value curve.

● Powerful data processing function, including: HR, HB, HV and other hardness

scale conversion.

● Qualified range can be set, automatic alarm over the limit, tester’s name,

sample name and other information can be input.

● With USB/RS232 interface, test data can be saved in U-flash directly in Excel

format.

● Indenter protective device equiped (testing sample size should over 15mm)

Product Application：

Industrial production, Inspection of product quality on processing technology. Ferrous and nonferrous metals, Hardened steel, tempered steel, annealed steel, hardened steel, sheet of various thicknesses, carbide materials, powder metallurgy materials, hardness and thermal spray coating.

Availability:

Quantity:



Inquire Add to Basket

Model:
uRocky-150/45
Brand:
Mikrosize

Product Description

Product Description

Technical Specification

Model	uRocky-150/45A
Product Name	Digital Twin Rockwell Hardness Tester
Rockwell Initial Test force	10Kgf(98.07N)
Superficial Rockwell Initial Test Force	3.0kgf(29.4N)
Rockwell Total Test force	60kgf(588N) 100kgf(980N) 150kgf(1471N)
Superficial Rockwell Total Test Force	15kgf(147.1N) 30kgf(249.2N) 45kgf(441.3N)
Rockwell Hardness Scale	HRA、HRB、HRC、HRD、HRE、HRF、HRG、HRH、HRK、 HRL、HRM、HRR、HRP、HRS、HRV
Superficial Rockwell Hardness Scale	15N、15TW、15W、15X、15Y、30N、30TW、30W、30X、30Y、45N、45TW、45W、45X、45Y
Hardness Conversion Scale	HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Hardness Testing Range	HRA:20-88、HRB:20-100 、HRC:20-70 、HRD:40-77 、HRE:70-100 、HRF:60-100 、HRG:30-94、HRH:80-100、HRK:40-100、HRL:100-120 HRM:85-115、 HRR:114-125 HR15N:70-94 HR30N:42-86 HR45N:20-77 HR15TW:67-93 HR30TW:29-82 HR45TW:10-72
Indenter	Diamond Rockwell Indenter, ф1.588mmBall Indenter
Loading Method	Automatic (Loading/Dwell/Unloading)
Executive Standards	BSEN 6508, ISO 6508, ASTM E18, GB/T230
Dwell time	0-99s
Hardness resolution	0.1 HR
Error of Test Force	< 1%
Hardness reading	Touch screen LCD display
Data Output	USB flash disk
Data Save	The measured values are saved on USB flash drive in Excel format
Conversion Scale	Rockwell, Brinell and Vickers
Test Height	220mm
Test Throat	200mm
Machine Dimension	560 * 220 * 800 mm
Net Weight	75kg
Power Supply	AC220 + 5%, 50 ~ 60 hz

Packing List

Item	Quantity	Item	Quantity
Diamond Rockwell Indentor	1	1.5875mm Ball Indentor	1
Hardness Block (HRC high and low、HRB、HR15N、HR30N、HR30T)	6	Large, Medium Test Anvil	Each 1
Spare Fuse (2A)	2	V-shaped Test Anvil	1
USB Disk,	1	Dustproof Plastic Cover	1
Power line	1	Product Qualification Certificate	1
Touch pen	1	Instruction Manual	1
