uRocky-150 Digital Rockwell Hardness Tester

Product Feature:
●uRocky-150CL is with Closed loop control system, high precision load cell structure
●8'' touch screen for user directly select the hardness scale and test force and displays hardness value, conversion scale, test force, dwell time, etc.
●With all kinds of rockwell hardness scales HRA HRB HRC etc and high resolution 0.1HR
●Automatic correction of high, medium and low hardness numbers
●Automatic correction of load, with the force accuracy increased by dynamometer.
●Automatically apply the initial test force and the main test force.
●Automatic testing process: Automatic loading - Dwell - Unloading, and automatic display hardness value.
●Curve display: test force, displacement depth change curve, real-time test force value curve.
Curve display: force, displacement depth change curve, real-time force value curve.
●Powerful data processing function, including: HR, HB, HV and other hardness scale conversion,
●Qualified range can be set, automatic alarm over the limit, tester’s name, sample name and other information can be input,.
●With USB interface, test data can be saved in U-flash directly in Excel format. easy to edit and process.
●Indenter protective device for optional purchase (testing sample size should over 15mm)

Product Application:
Industrial production, Inspection of product quality on processing technology. Ferrous and nonferrous metals, Hardened steel, tempered steel, annealed steel, hardened steel, sheet of various thicknesses, carbide materials, powder metallurgy materials, hardness and thermal spray coating.
Availability:
Quantity:
  • uRocky-150

  • Mikrosize

Product Description


Technical Specification

Model

uRocky-150WL

uRocky-150CL

Loading Method

Weights Loading

Closed Loop

Initial Test Force

10 Kgf (98.07N)

Main Test Force

60kgf(588N)   100kgf(980N)    150kgf(1471N)

Rockwell Hardness Scale

HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRR, HRP, HRS, HRV

Rockwell Test Range

HRA:20-95, HRB:20-100, HRC:20-70, HRD:40-77, HRE:70-100, HRF:60-100, HRG:30-94, HRH:80-100, HRK:40-100, HRL:100-120, HRM:85-115, HRR:114-125

Executive Standards

BSEN 6508, ISO 6508, ASTM E18, GB/T230

Dwell Time

0-99s

Hardness Resolution

0.1 HR

Error of Test Force

< 1%

Data Output

LCD Touch Screen

Data Save

The measured values are saved in USB flash in Excel format

Conversion scale

Brinell,Vickers, Superficial Rockwell

Test Height

200mm

Test Throat

200mm

Machine  Dimension

560 * 220 * 800 mm

Net Weight

70kg

Gross Weight &Package

90kg /780x470x940mm

Power Supply

AC220 + 5%, 50 ~ 60 hz

Packing List

Item

Qty

Instrument Mainframe

1pc

Diamond Rockwell Indentor

1pc

1.5875mm Ball Indentor

1pc

150mm Flat Test Anvil

1pc

55mm Flat Test Anvil

1pc

40mm V-shape Test Anvil

1pc

HRC Hardness Block(60~70)

1pc

HRC Hardness Block(20~30)

1pc

HRB Hardness Block(80~100)

1pc

U-flash

1pc

Touch Pen

1pc

Spare Fuse (2A)

1pc

Dust Cover

1pc
