iPress-4A Auto Metallographic Mounting Press(Electric Motorized)

iPress-2LA The hot mounting machine is used for inlaying small, difficult to hold or irregular metallographic and petrographic samples before grinding and polishing.
Availability:

Product Description

Product Feature

l After being embedded by this machine, it is convenient to grind and polish the sample, which is beneficial to observe the material structure of the sample under the metallographic microscope and test the hardness of the sample on the hardness tester.

l The inlay material of this machine is limited to thermosetting materials. The pressing temperature of different thermosetting materials can be adjusted and customized according to the material.

l This machine can automatically heat and pressurize. After pressing and forming, it will cool down and stop automatically. Open the upper cover and press the rising key to automatically raise the sample to take parts.

l This machine is a multi-functional water-cooled inlay machine for various samples. It has the advantages of large number of molds and short molding time.

Technical Parameter

Product Name

iPress-4A

Sample pressing diameter

ф30mm (ф25mm、ф40mm)choose any 2

Input power

220V   1650W*2

Heating temperature range

35~200℃

Insulation time range

1-99min

Cooling time range

0~60min

Overall dimension

677*490*545mm

Packing size

777*615*706mm

Net weight

94.2kg

Gross weight

110.25kg

Packing List

Main machine

iPress-4A

SET

1

Thermocouple


PCS

1

Plastic  spoon


PCS

1

Product manual


SHARE

1

Product certificate


SHARE

1

Inlet pipe, drain pipe


PCS

1 ea.

Pipe hoop


PCS

2

Fuse

5*20  15A

PCS

2

Power Cord


PCS

1
