iLeeb-110 Portable Hardness Tester

Features:
Compact plastic case，suitable for use under poor working conditions. Test at any angle, even upside down.
Wide measuring range. It can measure the hardness of all metallic materials. Direct display of hardness scales HRB, HRC, HV, HB, HS, HL
Large screen (segment LCD), showing all functions and parameters. With EL background light.
Large capacity memory could store 100 groups information.
Datapro Software to connect with PC via RS232 port. Micro printer support
Software calibration function.

Availability:

Product Description

Product Description

Technical Specifications:

l Measuring range：

(170-960)HLD,(17-68.5)HRC,(19-651)HB,(80-976)HV,(30-100)HS,(59-85)HRA,(13-100)HRB

l Measuring direction：360°（↓↖↗↘↙→←↑）

l Accuracy:±6HLD

l Hardness Scale：HL、HB、HRB、HRC、HRA、HV、HS

l Display：segment LCD

l Data memory：max. 500 groups（relative to impact times 32～1）

l Working voltage：3V（2 AA size alkaline battery）

l Continuous working period：about 100 hours（With backlight off）

l Communication interface：RS232

Main Application

l Die cavity of molds

l Bearings and other parts

l Failure analysis of pressure vessel, steam generator and other equipment

l Heavy work piece

l The installed machinery and permanently assembled parts.

l Testing surface of a small hollow space

l Material identification in the warehouse of metallic materials

l Rapid testing in large range and multi-measuring areas for large-scale work piece

Configuration:

	No.	Item	Quantity	Remarks
Standard Configuration	1	Main unit	1
	2	D type impact device	1	With cable
	3	Standard test block	1
	4	Cleaning brush (I)	1
	5	Small support ring	1
	6	Alkaline battery	2	AA size
	7	Manual	1
	8	Instrument package case	1
Optional Configuration	9	Cleaning brush (II)	1	For use with G type impact device
	10	Other type of impact devices and support rings		Refer to Table 3 and Table 4 in the appendix.
	11	DataPro software	1
	12	Communication cable	1
	13	Micro Printer	1
	14	Print cable	1
