iSurfa-100 Surface Roughness Tester

Product Features:
●The exterior is designed by drawing aluminium die, which is durable and has
remarkable anti-electromagnetic interference ability, and conforms to the new trend of design today.
●This is a pocket-sized instrument with an integrated sensor and main body.
●Low-power consumption ARM processor is used for data processing and calculation, which greatly improves the speed of measurement and calculation.
●The display LCD adopts 1.14 inch IPS TFT, with high brightness and no visual dead
angle, which is suitable for various occasions
●With a AA battery, it can work for a long time
●Equipped with Bluetooth adapter, it can communicate with Bluetooth devices such as
smart phones
●500 groups of measurement data can be stored
●Monitor and display the power of battery in real time, timely remind users to charge
and with charging progress prompt.
●The automatic shutdown function and low-power software and hardware design
make the instrument work for a long time, which is suitable for all kinds of field use.
●The sensor probe has a protective door, which effectively protects the sensor probe
and ensures the accuracy of measurement.
Measurable Workpiece Types:
It can be widely used for the detection of various metal and non-metal processed surfaces.
Availability:
Quantity:

Product Description


Technical Parameters

Measuring Range(µm )

Ra,Rq: 0.05~10.0


Rz,Rt: 0.1~50

Parameter(µm)

Ra,Rz,Rq,Rt

Travel Length(mm)

5.6

Sample Length(mm)

0.25,0.80,2.50

Evaluation Length(mm)

1.25,4.0

Display Error

±10%

Display Variability

<12%

Stylus Radius and Angle

90°(+5°,-10°)

Stylus Radius

10µm±1 µm

Measuring Force of Probe

≤0.016N

Force Change Rate

≤800N/m

Sensor Guide Pressure

≤0.5N

Battery

One 1.5V AA dry battery

Dimensions

73mm×28mm×62mm

Weight

220g

Working Environment Conditions

Temperature: -20℃~40℃


Relative humidity: < 90%


No vibration and corrosive medium around

Standard Delivery

Items

Qty

Main Unit

1

Calibration Block

1

Operating Manual

1

Certificate

1

Guarantee Card

1

Suitcase

1

Screwdriver

1

Bluetooth Adapter

1
