iCut-160A/180A Abrasive Metallographic Automatic Cutting Machine

Product Feature
●Automatically controlled by Siemens PLC to drive the stepping motor, achieve precise automatic control in X, Y, and Z-axis.
●Cutting speed can be adjusted according to hardness of the material to achieve fastest cutting effect, providing very high reliability and control capabilities.
●Electronic hand-wheel, automatic free conversion, X,Y,Z manual adjustment plus three-speed adjustment for better controlling of moving speed.
●Touch screen displays a variety of cutting data for more accurate and better positioning.
●3 cutting functions: chop cutting, flat push cutting, and sweep cutting.
●Electro-mechanical separation design for easy cleaning of the cutting chamber and the safety of the spindle motor, and the motor in the cutting chamber is protected by waterproof isolation.
●Observation window is installed on the safety protection door of the cutting chamber, allowing users to easily observe the entire cutting process of the sample.
●The cutting chamber is equipped with LED lighting, providing effective illumination of the entire cutting area, increasing brightness and clarity within the workspace.
●Low noise, convenient operation, attractive appearance, and safety in use.
● Vertical machine consists of an upper part (safety cover), a middle part (frame), a right sliding door, a side door, a lower frame (electrical box), fixtures, a flushing water gun, and an independent cooling water tank.
● Easier to maintain machine parts and handle large workpieces. The sliding door and hinged door provide more space and unrestricted access, making it easier to load large workpieces into the correct position. Workpieces can also be loaded into the cutting chamber from the top, front, and left sides.
●Fully enclosed structure with a transparent protective cover for observation during cutting.
● Cooling water system for storing coolant.

Product Application
●Designed for large workpieces and high-capacity cutting.
●It is one of the essential devices for sample preparation in laboratories.


Availability:
Quantity:

Product Description

Technical Specification

Product Name

Abrasive Metallographic Automatic Cutting Machine

Model

iCut-160A

iCut-180A

Cutting Method

Chop cutting, flat push cutting, continuous feed, pulse feed

Cutting Speed

0.03-1mm/s (adjustable step 0.01mm/s)

Frequency Control

500~2300 rpm

Max Stroke

Z-axis 260mm; Y-axis 270mm;X-axis 255mm

Working Table Size

550*280mm,  550*170mm

Max Cutting Diameter

φ160mm

φ180mm

Motor

7.5KW

Power Supply

380V/ 50Hz

Machine Dimension

1580*1450*1900mm

Packing Size

1700*1700*2000 mm

Net Weight

1400kg

Gross Weight

1600kg

Packing List

Item

Specification

Qty

Machine Mainframe

iCut-160A/180A

1 set

Water Tank

(With water pump)

1 pc

Cut-off Wheel

450×3×32mm

5 pcs

Inlet Pipe

Corrosion-resistant steel wire hose

1 pc

Cutting Fluid

iCut-160A/180A

2 bottles

Hose Clamp

iCut-160A/180A

2 pcs

Wrench

36mm

1 pc

Wrench

17-19mm

1 pc

Hex Wrench

iCut-160A/180A

1 pc

Instruction Manual

iCut-160A/180A

1 copy

Product Certificate

iCut-160A/180A

1 copy

Packing List

iCut-160A/180A

1 pc
