VMQ-3020 Splicing Instant Video Measuring System

VMQ-3020 composite splicing measuring instrument adopts double telecentric high-resolution optical lens, combined with high-precision image analysis algorithm, image splicing algorithm, and incorporates the principle of one-key flash measurement. The instrument can automatically locate the measurement object, match the template, measurement evaluation and report generation according to the shape of the workpiece, which really realizes one-key fast and accurate measurement.
Availability:
Quantity:
  • VMQ3020

  • Mikrosize

Product Description

technical specification

Model

YT-5040S

Stationary range(mm)

63×42

Motion range(mm)

500×400×200

External dimensions (mm)

900×800×1650

Weight (kg)

450

Load capacity (kg)

20

image sensor

20 megapixel industrial   camera

camera shot (in a movie etc)

telecentric optical lens

magnification

0.088X

Accuracy (μm)

±(3+L/100)

Minimum display unit (mm)

0.0001

Z-axis working distance(mm)

200

light source

1000-level   program-controlled light source / surface light: ring surface light source   Contour light: telecentric parallel light source (optional surface light:   external coaxial light)

image processing

IVT advanced image analysis   method, 256 gray levels, 10:1 sub-pixel processing technology

hardware

FOM-FS software

working environment

environment Temperature: 22℃±2℃ Humidity: 30~80%   / Vibration: <0.002mm/s, <15Hz

power supply

220V/50Hz



Configuration list

serial number

name

qty

note

1

Composite   Splicing Gauge

1   unit

Machine   base, Z-axis column, XY table, exterior sheet metal, etc.

2

Motion   Controller

1

standard configuration

3

servo   motor

3

standard configuration

4

Workbench   Glass

1

standard configuration

5

telecentric   lens

1

standard configuration

6

industrial   camera

1

standard configuration

7

Ring   surface light source

1

standard configuration

8

telecentric   parallel light source

1

standard configuration

9

Camera   Cable, Serial Cable

1   each

standard configuration

10

calibration   sheet

1

standard configuration

11

calculator


Includes mainframe, 24-inch monitor, keyboard and mouse set

12

FOM-FS   software

1   copy each

Includes encryption lock

13

Software   manual

1   copy each

standard configuration

14

Certificate   of Conformity, Warranty Card

1   copy each

standard configuration
