VMQ-100 Instant Video Measuring System

Product Advantage
1、One-key Instant Measuring, Batch Testing
A) Measuring Sample can be placed randomly without fixture positioning, software can identify and match automatically;
B) Unlimited dimension measurement , and measurement task can be completed within 1 s C)CAD drawing import for direct measurement,
D)One-time measurement ofthe same type of measuring sample
2、Accurate Calculation and High Repeatability
A)Unique patent technology of Edge extraction and lens distortion correction B)Automatic lighting,, greatly improve the repeatability;
C)It can be compared with the measurement accuracy and repeatability of traditional Video Measuring Machine。
3、Easy to operate without training
A) Anyone can get started quickly without training
B) Simple interface, intelligent measurement , the optimized operation process , real-time operation tips
C ) All measurement data can be automatically recorded, statistical analysis can be generated with one key. measurement results can be printed in various file formats or directly printed by printer.
4、Various function, automatic report
A ) The software is divided into three functional models: measurement setting, continuous measurement and statistical analysis;
B) Continuous measurement can be used for real-time measurement, and it can judge NG / OK without pressing the key, providing 80 tools of extraction and analysis , including feature extraction tools (such as maximum point, center line, arc, peak circle, etc.), auxiliary tools (such as arbitrary point line circle, fitting line, fitting circle, tangent line, inscribed circle, etc.), intelligent annotation tool, geometric tolerance tool, special application tool(such as R angle, etc.).
Availability:
Quantity:
  • VMQ-100

  • Mikrosize

Product Description

VMQ-100 Instant Video Measuring System

Product Advantage

1、One-key Instant Measuring, Batch Testing

A) Measuring Sample can be placed randomly without fixture positioning, software can identify and match automatically;

B) Unlimited dimension measurement , and measurement task can be completed within 1 s C)CAD drawing import for direct measurement,

D)One-time measurement ofthe same type of measuring sample


2、Accurate Calculation and High Repeatability

A)Unique patent technology of Edge extraction and lens distortion correction B)Automatic lighting,, greatly improve the repeatability;

C)It can be compared with the measurement accuracy and repeatability of traditional Video Measuring Machine。


3、Easy to operate without training

A) Anyone can get started quickly without training

B) Simple interface, intelligent measurement , the optimized operation process , real-time operation tips

C ) All measurement data can be automatically recorded, statistical analysis can be generated with one key. measurement results can be printed in various file formats or directly printed by printer.


4、Various function, automatic report

A ) The software is divided into three functional models: measurement setting, continuous measurement and statistical analysis;

B) Continuous measurement can be used for real-time measurement, and it can judge NG / OK without pressing the key, providing 80 tools of extraction and analysis , including feature extraction tools (such as maximum point, center line, arc, peak circle, etc.), auxiliary tools (such as arbitrary point line circle, fitting line, fitting circle, tangent line, inscribed circle, etc.), intelligent annotation tool, geometric tolerance tool, special application tool(such as R angle, etc.).


Software Function

1、Software Interface

Software main interface is divided into three functional models: measurement setting, continuous measurement and statistical analysis. Simple , easy to use.

Software Interface


2、Measurement Setting

In this model, we can quickly extract geometric elements and do dimensioning to complete the measurement setting.

Measurement Setting


Measurement Setting


Measurement Setting


Measurement Setting



3、Continuous Measurement

After measurement setting , software enters to the continuous measurement model, which

can be doing rapid and accurate batch measurement.


4、Statistical Analysis

Mikrosize software provides a variety of extraction and analysis tools, the statistical analysis

interface has [statistical value], [trend graph], [histogram] and [data. Measurement results and main statistical information (such as average, σ, 3σ, 6σ, Cpk, etc.) will be automatically recorded and fifiled. The operator can select different fifilter conditions to extract history records.



5、Control producing process and improve product quality

The trend graph can monitor the abnormal of producing equipment and producing process

through the regular tendency of measured value, such as monotonic change and periodic change of measured value.


Histogram can reflflect the flfluctuation and distribution of product quality, and intuitively transfer the information of quality status, which can be used to judge and predict product quality and unqualifified rate. By quality diagnosis,SPC uses statistical methods to monitor the change tendency of product quality and producing process. It plays a preventive role in the producing process as to improve the product quality.



6、Test report Generated with one key

The test results report and SPC analysis report can be automatically generated with one key


7、 Special Function

A) Intelligent extraction function

The line, arc and circle can be extracted automatically by mouse clicking the area near the

elements to be measured.


B) Contour extraction function

It provides various methods of contour extraction and contour conversion tools, which can measure irregular objects and small objects.


C) Automatic lighting

When a single lighting unit, falling lighting or projection lighting is used, the software can

automatically and quickly determine the best illumination brightness (within 5 seconds).


D) Quick Module Search

For the measurement of a large number of different spare parts, the software can automati

cally fifind out the corresponding measurement program (within 0.1s) from the measurement

module pool after placing a spare part.


Application

Fom software can be used in machinery, electronics, mold, injection molding, hardware, rubber, low-voltage electrical appliances, magnetic materials, precision stamping, connectors, terminals, mobile phones, household appliances, printed circuit boards, medical devices, watches, knives and other fifields


1. Gear


2. Mobile Phone and Watch


3. Semiconductor (film)


4. Hardware



Specification


Instrument Dimensions

480×240×680

Instrument Weight

30KG

Working Stage Capacity

3KG

Software

Fom2d

Camera

5 millions Pixels CCD Industrial Camera

Lens

Double Telecentric Lens

Illumination

Program controlled parallel light or telecentric parallel light,

each section of brightness is controlled independently

Field of view


30mm~100mm


Focus

Manual

Measuring Accuracy

±3 µm

Measuring Function

Point, line, circle, multipoint line, multipoint circle, automatic circle,

arc, multisection circle, automatic R angle, contour scanning,

fifixed point, peak line, circle, etc

Tagging Function

Aligned, vertical, angular, radius / diameter

Geometrical Tolerance

Straightness, roundness, symmetry, profifile, etc

Virtual Structure

Center line, bisector, tangent point, tangent point of circle line,circle center, line center, etc

Automatic Template Matching

Support

Report Function

SPC analysis report ( CPK, CA , PPK, CP, PP )

Software Customization

CAD import profifile analysis, automatic management link,

APP management application

Measuring Quantity

99 pieces/second

Template quantity

Unlimited

Power

AC100-240V 50/60Hz

Working Environment

Temperature 23 C ± 2 C humidity 20% to 80% RH



Packing List


Packing List

Packing List

Packing List

Machine Mainframe

Dell 24 inch Computer

Mikrosiz Measuring Software

Telecentric Lens

High Pixel Camera

Surface Lighting

Calibration Block

Power Line

Product Certifificate
