Take Eight minutes to learn tips for using MS-1305D Insertion Extraction Forc Plug Testing Machine byMikrosizeEquipment Supplier. Old chap, when you are about to commence work with the MS - 1305D Insertion/Extraction Force Tester, it is of paramount importance to strictly adhere to the following professional operation procedures. This is the very core of ensuring accurate measurement data and the stable operation of the instrument. I. Pre - measurement Preparation (I) Instrument Appearance Inspection Prior to initiating any operation, you must conduct a comprehensive visual inspection of theMS - 1305D Insertion/Extraction Force Tester with meticulous attention. Thoroughly examine the device's display screen for any cracks, breakages, or other minor malfunctions that may affect the reading and functionality. The instrument's housing and all components should be free from any physical damage. Situations such as scratches, dents, and looseness must be excluded. If anything unusual is detected on the appearance of the instrument, to avoid measurement errors and instrument malfunctions, you must cease usage immediately and promptly contact professional instrument maintenance technicians to rectify the issue. (II) Equipment Calibration Calibration is of utmost significance for ensuring the accuracy of measurement results. In accordance with the instrument's calibration procedures, install the standard insertion/extraction force test module in the designated position to ensure a secure installation. Subsequently, initiate the calibration procedure, which is typically achieved by operating specific buttons on the instrument panel. Throughout the entire calibration process, the equipment must remain stationary and stable, avoiding any potential vibration or displacement. During the calibration process, the instrument's display screen will show the calibration progress and relevant parameters in real - time. After successful calibration, the instrument will notify us through a prompt tone and a specific display indication. (III) Test Parameter Setting Based on the specific requirements of the product to be tested, precisely set various test parameters in the instrument's operation interface. For example, set the insertion/extraction speed, stroke, maximum test force, etc. The setting of these parameters is directly related to the accuracy and validity of the test results, so extreme caution must be exercised. II. Measurement Process (I) Test Sample Preparation Carry out necessary cleaning and pretreatment on the test sample, removing impurities such as dust and oil stains on the surface to ensure that the sample surface is clean and tidy. Meanwhile, inspect the interface part of the sample for any damage or deformation. If there are any problems, the sample needs to be repaired or replaced in advance. (II) Installation of Test Sample Accurately install the prepared test sample on the test fixture of the testing machine without fail. Ensure that the sample is firmly installed and will not shake or fall off during the test. After installation, some simple manual checks can be carried out to ensure that the connection between the sample and the test fixture meets the requirements. (III) Conducting the Test Once all preparations are complete, press the start button of the instrument to begin the insertion/extraction force test. During the test, closely monitor the data changes on the instrument's display screen and the operating status of the equipment. Ensure that the test process is smooth without any abnormal noise or vibration. If any abnormal situation is detected, immediately stop the test and inspect the equipment and sample. (IV) Recording Test Data After the test is completed, the instrument will display and store the insertion/extraction force data of this test. You need to carefully read and record these data. To ensure the reliability of the data, it is recommended to conduct multiple tests on the same batch of samples under the same conditions and then take the average value as the final result. III. Post - measurement Treatment (I) Data Export and Analysis If you need to further analyze and process the test data, you can export the data to external devices such as a computer through the data transmission interface equipped with the instrument. Use professional data analysis software to collate and analyze the data in order to draw more valuable conclusions. (II) Instrument Cleaning and Maintenance After the test work is completed, carefully clean and wipe the outer surface of the instrument, the test fixture, and other exposed components with a clean and soft cloth, removing all dust, dirt, and other impurities attached to the surface. At the same time, check whether each component of the instrument is loose or damaged. If necessary, tighten or repair it in a timely manner. Regularly conduct comprehensive maintenance of the instrument, including but not limited to checking the operating condition of the motor, lubricating mechanical components, etc., to ensure that the instrument is always in good working condition. (III) Instrument Shutdown After completing all test tasks and data processing work, be sure to press the power button of the instrument to completely shut down the instrument. This not only helps to save energy but also effectively prevents the instrument from being damaged due to accidental operations or environmental factors when it is idle. By strictly following the above - mentioned operation steps, the performance advantages of the MS - 1305D Insertion/Extraction Force Tester can be fully exploited, and accurate and reliable test data can be obtained. If you encounter any technical problems or have any questions during the operation process, remember to consult the instrument operation manual in a timely manner or contact the professional technical support team for assistance. |
