Mikrosize’s Ultrasonic Flaw Detector

 As a top-tier Measuring Testing Instrument from Mikrosize, the iFlaw-1500 stands out for its compact design and superior quality, featuring a spacious full-VGA transparent display paired with Olympus’ patented digital high-dynamic-range receiver—this combination delivers stable, clear A-scan images in most lighting conditions. Compliant with the ISO-22232 standard, it offers complete standard and optional flaw detection functions, while onboard report production tools and a comprehensive data archiving system simplify the collection and reporting of high-quality inspection data. Sturdy and durable, the instrument follows ergonomic design principles, making it adaptable to diverse testing environments, and its flexible PerfectSquare pulse generator plus 30 digital filters further enable it to handle most detection tasks effectively. This Measuring Testing Instrument (supplied by Mikrosize) also combines Olympus’ industry-leading conventional flaw detection performance with the efficiency of intuitive operation and compact portability, thanks to its efficient menu system and shortcut key access that create an easy-to-use, high-quality defect detection platform.

Mikrosize’s iFlaw-1500—your reliable Measuring Testing Instrument—suits most testing scenarios, ranging from laboratory bench testing to harsh and dangerous outdoor sites. Its shuttle knob meets the IP66 rating standard, and the browsing key area complies with IP67; additionally, the instrument has passed strict testing against relevant environmental and reliability standards, ensuring users can trust its operational performance and durability in most conditions. Key features of this Measuring Testing Instrument include an ISO-22232 compliant design, PerfectSquare adjustable square pulse generator, full-screen A-scan mode, digital high-dynamic-range receiver, 30 digital filters (for enhancing signal-to-noise ratio), 2 kHz pulse repetition frequency (for fast scanning), shuttle knob or browsing key area (for adjusting configurations), sunlight-readable full-VGA display, over 15 hours of battery life, standard dynamic DAC/TCG and airborne DGS/AVG, multiple onboard report formats, MicroSD memory card (for data transfer), optional corrosion module software with encoded B-scan, USB (OTG) port (for communication with PCs), alarm and VGA output, and optional analog output.

The design of Mikrosize’s iFlaw-1500—this user-centric Measuring Testing Instrument—focuses on delivering high-level flaw detection performance through an easy-to-use basic instrument, adhering to ergonomic principles for intuitive practicality, so both experienced and novice ultrasonic testing personnel can operate it with ease. Its user interface builds on the industry-leading iFlaw-1500 flaw detector, featuring a simple menu structure that facilitates instrument settings, calibration, and software function adjustments, along with EPOCH brand iconic shortcut keys to access important detection functions like gain, gate adjustment, screen freezing, and file saving. The interface also supports multiple languages, making it usable by operators of any level. As a premium Measuring Testing Instrument supplied by Mikrosize, the iFlaw-1500 is equipped with a full VGA (640 × 480 pixels) resolution display; its horizontally wide and vertically narrow panel design optimizes the size and readability of A-scans on the high-quality display, and the screen uses transparent technology—with strong backlighting in dimly lit indoor environments and ambient light as a supplementary backlight in direct sunlight—to provide high-quality, clear images in most cases. Its full-screen mode further enhances the vividness and clarity of screen images, offering the largest A-scan among all EPOCH series flaw detectors.
