How Do You Ensure Deformation-Free Cutting?

High-Speed Precision Cutting Machine: An Ideal Solution for Superior Sample Preparation

The high-speed precision cutting machine stands as a cornerstone technology for industrial and research facilities demanding the highest quality in sample preparation. This advanced device is expertly engineered for precise, deformation free cutting of a vast array of materials. Its capabilities extend to metals, intricate electronic components, brittle ceramic materials, various crystals, hard alloys, robust rock and mineral samples, concrete, a range of organic materials, and sensitive biomaterials such as teeth and bones. Supplied by Mikrosize, a trusted name in precision equipment, and categorized under advanced Measuring and Testing Instruments, this machine guarantees the integrity of your samples from the very first step of analysis.

Designed for unparalleled performance and ease of use, the machine is controlled by a sophisticated Programmable Logic Controller (PLC), ensuring high positioning accuracy and exceptional operational stability. It boasts a wide cutting speed range from 0.01 to 3.00 mm/s, adjustable in fine 0.01mm steps, providing unmatched control for different material properties. The grinding wheel speed is equally impressive, variable from 500 to 5000 rpm, allowing for optimal cutting conditions. With a powerful 1000W cutting motor and a maximum Y-axis travel of 200mm, the machine possesses strong cutting ability to handle even the most challenging specimens. The robust circulation cooling system is integral to preventing thermal damage, ensuring that samples remain free from heat-induced alterations.

Operation and control are centralized through a large, intuitive touch screen display. This interface allows operators to easily preset the feed speed and monitor the entire cutting process in real-time. The system significantly reduces operator fatigue through its automatic cutting cycles, which not only enhances comfort but, more importantly, ensures remarkable consistency in sample production. This repeatability is critical for obtaining reliable and comparable data in both quality control and research settings. The spacious and brightly lit cutting chamber, coupled with a safety switch, provides a secure and highly visible working environment. Furthermore, the machine features comprehensive alarm prompts to immediately notify the user of any operational issues, thereby safeguarding both the equipment and the sample.

As a premier Measuring and Testing Instrument offered by Mikrosize, this high-speed precision cutting machine incorporates all the essential features for efficient and reliable sample preparation. Its combination of power, precision, and user-friendly automation makes it an indispensable asset. It is unequivocally one of the ideal equipment choices for industrial and mining enterprises, as well as scientific research institutes, dedicated to preparing high-quality samples for accurate analysis and groundbreaking discoveries.

Specification:

Cutting Speed: 0.01~3.00mm/s (adjustable in 0.01mm steps)

Grinding Wheel Speed: 500~5000rpm

Maximum Travel: Y-axis 200mm

Cutting Blade Size: 200x32x1mm

Cutting Power: 1000W

Power Supply: 220V 50Hz
