Product Description
Technical Specification：
Technical Specification | HMV-3015 | HMV-3020 |
(XY/Z)Measuring range(mm) | 300x150x150 | 300x125×200 |
Machine dimension(mm) | 650x800x1600 | |
Operation mode | Manual | |
Magnification | 20-120X | |
Screen dimension | 19"monitor(HV)or 19"touch-type LED monitor (HTV) | |
Lens work range | 95mm | |
X,Y-axis resolution | 1um | |
Accuracy | ≤(3+L/200)um | |
Repeatability | 5um | |
Measuring software | Quick Measuring 2.0 | |
Color CCD Camera | 430,000pixel | |
Suitable environment | Workshop and Metrology room | |
Stage load capacity | 15Kg | |
Standard Delivery：
Name | Qty |
Measuring Software | 1 set |
Color CCD Camera (MC1 (430,000 Pixels)) | 1 pc |
Zoom Lens General Zoom Lens (0.7~4.5x) | 1 pc |
Vision Capture Card 7130 (VC1) | 1 pc |
Basic Adjustable LED Light Source | 1 pc |
Optional Delivery：
Accessory Category | Model/Specification |
Camera Upgrade | MC2 (480TVL, 0.1Lux/F1.2) |
MC3 (480TVL, S/N Ratio 57dB) | |
Zoom Lens Upgrade | Navitar Click Zoom Lens (0.7~4.5x) |
Coaxial Zoom Lens (0.7~4.5x) | |
Motorized Zoom Lens (0.7~4.5x) | |
Lens Accessories | 0.5x Adjustable Objective |
2x Adjustable Objective | |
0.5x CCD Adapter | |
2x CCD Adapter | |
Ultrazoom Objective (5x/10x/20x/50x) | |
Light Source Upgrade | 4-Division LED Light Source |
40-Division LED Light Source | |
Point Fiber Light Source | |
Mechanical Accessory | Working Cupboard ST04 |
Precision Accessory | Renishaw MCP Touch Probe (K1/K2, 1-2mm) |
