iCoat-200 Coating Thickness Gauge

Product Feature：
. With different external probes, the gauge can be applied to measuring thickness of non-magnetic coating on magnetic metal substrate, as well as non-conductive coating on non-magnetic metal substrate.
. Two measuring modes: single or continuous, changeable.
. Two work modes: direct or group, changeable.
. High precision mode: multiple measurements and automatically data filtering method to reduce disturbance of measure results
. Temperature compensation: compensate the measurement distortion caused by the drifting of temperature.
. Give five statistical values: average（ MEAN ）, maximum（ MAX ）, minimum(MIN), measure number（ No. ）, and standard deviation(S.DEV).
. Two calibration methods can be applied to the gauge; And the system error of the probe can be corrected with the basic probe calibration method.
. Data storage: up to 500 measurements storage.
. Set boundary: alarm while measurements out of boundary.
. Battery information indicates the rest capacity of the battery.

Product Application：

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Description


Working environment	Temperature	0℃ ~ 40℃
	Humidity	20%RH～90%RH
	Without strong magnetic field
Power	2*AA Alkaline batteries
Size and weight	Size	151mm×76mm×38mm
	Weight	about 240g
Probe type	F	N
Measuring principle	Magnetic induction	Eddy current
Measuring range	0 ～1500 um	0 ～1500 um
Low range resolution	0.1 um	0.1 um
Accuracy	Zero calibration	±(2%H+1) um	±(2%H+1) um
	Two point calibration	± [(1 ～2)%H+1] um	± [(1 ～2)%H+1] um
Measuring Condition	Min. radius of curvature	Cx. 1.5 mm	Cx. 3 mm
	Min. radius of area	Φ7 mm	Φ5 mm
	Critical thickness of plate	0.5 mm	0.3 mm

Item	Quantity	Remarks
Main Unit	1
Probe	1	F or N or FN
Calibration Foils	6 PCS
Zero plate	1	Iron or Aluminum
Battery	1	2 x AA Alkaline Batteries
User Manual	1
Certificate	1
Warranty card	1
Feedback submission	1
