MMD-HPG3600 Roughness and Profile Measuring Machine

Product Feature
●No need to change the sensor, measuring needle
●Achieves a measurement of roughness, waviness, profile analysis at the same time
●One measurement can analyze the roughness of different areas of the workpiece and improve the measurement efficiency
●Simple stylus replacement design, once installed, no calibration required
●Software annotation CAD, zero threshold for software entry. Arc, line automatic recognition
●Supports import and export of DXF format files and export of customized CAD formats.
●Supports continuous labeling, benchmark labeling, and any insertion point

●Supports free rotation of graphics and coordinates. The current position of axes X and Z1 can be monitored
●It has the functions of automatic contact, automatic lifting and automatic backtracking
●The feature points such as intersection, circle center, arc intersection and tangent point are automatically generated and captured when the capture switch is turned on
●Normal Angle, arc, horizontal, vertical, linear and so on can be marked even in the case of non-proportional amplification
Product Application
●It can accurately measure the surface of the parts to ensure the interchangeability and accuracy of the parts, thereby improving the performance and reliability of the whole machine
●It can not only be used to test the surface roughness of automobile bodies and parts, but also it can ensure the appearance of the vehicle is smooth and smooth, reduce wind resistance and noise
●It can be used to detect the surface roughness of aircraft, rockets and other aircraft to ensure that the surface is smooth and flat, reduce air resistance, and improve flight efficiency. At the same time, for some key components such as turbine blades and bearings, accurate measurement of their surface roughness can ensure their stability and reliability in extreme environments

Availability:

Quantity:



Inquire Add to Basket

Product Description

Product Description

Technical Parameters

Item		Parameter
Measuring Range	X-axis	0-100mm
	Z1（Sensor）	40mm( Roughness and Shape in the same range MAX=60mm) Simultaneous measurement and analysis of shape and roughness without changing sensors
	Z-axis Height	500mm
	Minimum Bore	6mm
X-axis	Straightness	≤0.5µm/100mm
	Resolution	1 nm
	X-axis（L=X) Shaft Moving Guid Distance	≤ ±(0.5+0.02L)μm
	Driving Mode	Electric Control
	Velocity of Motion	Low \ Medium \ High speed, can customize the speed
	Rail Motion Mode	Maintenance-free adaptive high precision grinding ultra-precision linear guide
Z-axis	Maximum Moving Speed	10mm/s
	Minimum Moving Speed	0.5mm/s
	Positioning Accuracy	0.05mm
	Z-axis Type	Lightweight frame type vertical shaft
Z1 Sensor	Type	Low noise digital grating sensor
	Resolution	1 nm
	Z1 axis (H=Z1 axis Direction Measuring Height)	≤±（0.6+\|0.02H\|）μm （H Measuring Height）
Measurement Repeatability		≤±3％
Arc Radius Measurement Accuracy		≤±（0.8+R/12）μm （0.5mm<R<10mm）
Distance Measurement Indication Error		≤（1.2+L/100）μm（L：mm）
Angle Measurement Accuracy		≤±1′
Residual Noise of Roughness Measurement		≤0.005um
Roughness Indication Accuracy		≤±（5nm+2.5％A) A is the Nominal Value of Ra measured in μm
Rating Length		λc×1、2、3、4、5、6、7、8（Customizable）
Cut-off Wavelength		0.025、0.08、0.25、0.8、2.5、8mm
Climbing Angle		Up 77°, Down 88°
Measuring Speed		0.02mm ~5.0mm/s（Customizable measurement speed）
Measurement Mode		Sensor movement
Measure Needle Sensing Direction		Z1+/Z1-( Move up and down）
Power Supply		AC 220V±10% 50Hz
Environmental Conditions		Temperature(T)：10～30℃； Relative humidity(RH)：＜85% No visible sources of vibration at the installation site

Packing List

Part Name	Item Description	Qty
Mechanical Part	Main integrated ergonomic instrument stand	1 set
	Natural marble countertop, shock-proof floor integrated platform	1 set
	High precision grinding ultra-precision linear guide system	1 set
	High speed movement system of square column	1 set
	Digital sensor	1 set
	Work-box	1 set
	Roughness standard	1 set
	Contour shape standard(Silicon carbide standard ball G10 grade, measuring block 2mm and 5mm)	1 set
	Single section oblique probe	2 pcs
	Sharp stylus	1 pc
	Bore stylus	1 pc
Magnetic Quick Disconnecting Straight Rod	Measuring rod	2 pc
Electrical Part	Electrical control system	1 set
	Dedicated Computer System (Brand: Lenovo) Processor I5 、Inline Dimension8G、Hard Disk 512GB	1 set
	Monitor (Brand: Lenovo)	24 inches
	Wireless mouse and keyboard (Brand: Lenovo)	1 set
	HP ink jet printer(Brand: HP)	1 set
	Specialized measurement software	1 set
	Chinese version instruction manual (including electronic version)	1 set
	Product warranty card	1 set
	Product packing list	1 set
	Product certificate	1 set
	Equipment acceptance sheet	1 set
	Work-Box	1 set
