Mikrosize Digital Inverted Metallographic Microscope: Precision for Material Science
As a leading supplier of hardness testers, video measuring systems, microscopes, and metallographic equipment, Mikrosize provides advanced Measuring and Testing Instrumentation. Our Digital Inverted Metallographic Microscope is a cornerstone instrument for materials analysis, combining classic optical excellence with modern digital scalability.
Product Introduction
This microscope is a refined classic, engineered for demanding industrial and laboratory environments. It features high-quality, long-working distance, infinity-corrected flat-field objective lenses that deliver exceptional image clarity, contrast, and true flat-field performance across the entire field of view. The inverted design is key for metallography, allowing easy analysis of large, heavy, or irregular samples—from metal castings and engine components to geological slices and ceramic substrates—with minimal preparation.
Its applications are extensive. It is widely used in factories and labs for casting quality control, raw material inspection, failure analysis, and detailed study of microstructures after heat treatment, welding, or machining. It is indispensable for investigating surface phenomena like cracks, grain boundaries, coatings, and phase distributions. Effectively, it serves as a primary tool for the metallographic analysis of steels, non-ferrous metals, cast iron, and coatings. Beyond metallurgy, it is equally vital for petrographic analysis in geology and the examination of ceramics and composites in industrial research.
A core advantage is its digital readiness. The system can be seamlessly upgraded into a digital microscope camera system based on customer needs, bridging traditional observation with digital documentation and analysis.
Scalable Digital Functionality
Mikrosize offers high-resolution digital camera systems that integrate directly with the microscope. The accompanying software captures, displays, and processes live video and high-resolution images on a computer. This enables users to edit, annotate, save, print, and share images effortlessly, facilitating collaboration and reporting. This digital shift aligns with Industry 4.0 trends, making it ideal for users seeking a "digital metallographic microscope" or "microscope with camera" for modern labs.
Quantitative Metallographic Analysis
The true power of the system is unlocked with the optional "Professional Metallographic Structure Quantitative Analysis Software." This transforms the microscope from an observation tool into a complete analysis workstation, providing precise, repeatable measurements compliant with international standards (ASTM, ISO, etc.).
Key software capabilities include:
Grain Size Measurement & Rating: Per ASTM E112, crucial for correlating microstructure with mechanical properties.
Non-Metallic Inclusion Rating: Classifies inclusions per standards like ASTM E45 for steel cleanliness assessment.
Phase Content Measurement: Quantifies percentages of phases (e.g., pearlite/ferrite).
Graphite Nodularity Rating: Specialized analysis for ductile iron.
Layer Thickness Measurement: Measures coating, plating, carburizing, or decarburization depths accurately.
Porosity & Particle Analysis: Quantifies porosity and characterizes particle distributions.
The software generates comprehensive statistical data and professional reports, making it essential for quality control, R&D, and failure analysis.
Integration with the Mikrosize Ecosystem
As a total solution provider, Mikrosize designs this microscope to synergize with its broader portfolio. A sample analyzed microscopically can be directly tested for hardness on a Mikrosize hardness tester or pre-screened dimensionally on a Mikrosize video measuring system. This integrated measuring and testing instrument ecosystem streamlines workflows in quality assurance and materials testing labs.
Conclusion
The Mikrosize Digital Inverted Metallographic Microscope represents the fusion of superior optics, digital innovation, and specialized quantitative analysis. It is a complete platform for material science research, metallurgical testing, and quality assurance. By choosing Mikrosize, you partner with a dedicated supplier committed to providing the tools for excellence in a quality-driven market. Whether your needs focus on "grain size analysis," "inclusion rating," "coating thickness measurement," or "digital microscopy," this microscope delivers the profound insights and precise data required for innovation and reliability.
