●It can evaluate five measurement types: Roughness profile, Waviness profile, Primary profile,Abbott curve and Motif.
●Wireless WiFi communication allows the operator to remotely control and use it more conveniently.
●High precision large stroke guide rail, length up to 50mm.
●Sensor range ± 1000 μ m.
●The parameters are comprehensive, including 5 measurement types and a variety of national standards.
●Measure WITH or WITHOUT a guide head, and the measurement of small values WITHOUT a guide head is also very accurate.
●The stylus can be directly replaced,and the replacement operation is convenient, which can realize the measurement in different scenes.
●The sensor can be switched vertically or in the same direction with the guide rail at will, so the measurement of deep grooves can be made from the side without being limited by the depth of the stylus and groove.
●The data storage is convenient.
●The analysis algorithm including multiple filter methods can be matched at will to meet the requirements.
●It supports automatic multiple calibration of standard blocks, so that the calibration error is greatly reduced.
| Quantity: | |
|---|---|
Product Description
Range | X:50mm/Z:±1000μm | ||
Resolution | X:0.0016μm/±50μm-0.016μm/±1000μm | ||
Straightness | 1μm/50mm | ||
Parameters | Roughness Profile | Ra75,Rq,Rp,Rv,Rc,Rt,S,R3z,PPI,Ra,Rsk,Rku,Ry,Sm,RΔa,RΔq,Rz,Pc,Rλa,Rλq,lr,RSm,Rz94,RPc,RS,Rz.I,Rpm,HSC | |
Waviness Profile | WCA,WCC-q,WCC-p,WCC-v,WCC-m,WCC-Sm,WCA,WC-q,WC-p,WC-v,WCM,WC-Sm,WC-t,Wa,Wq,Wsk,Wku,Wp,Wv,Wz,Wc,Wt,WSm,WΔq,WPc | ||
Primary Profile | Rsk,Rku,Rmax,Sm,Δa,Δq,Rz,λa,λq,lr,TILT A,AVH,Hmax,Hmin,AREA,Rz.J,Pa,Pq,Psk,Pku,Pp,Pv,Pc.I,Pt,PSm,PΔq,PPc,Pc | ||
Abbott Curve | Rk,Rpk,Rvk,Mr1,Mr2,V0,K,A1,A2 | ||
Motif | NCRX,AR,R,Rx,NR,CPM,SR,SAR,AW,W,Wx,Wte,NW,SW,SAW,Rke,Rpke,Rvke,Mr1,Mr2,V0,K | ||
Evaluation Curve | Roughness profile,Waviness profile,Primary profile,Abbott curve,Motif | ||
Characteristic Curve | Abbott curve (Rmr(c),Rmr2(c),Rδc(c),tp(c),tp2(c),Htp(c)),Amplitude frequency analysis curve,amplitude distribution curve | ||
Form Remove | Global, first half, second half, center, 2 points, curve | ||
Filter Type | Gaussian,FFT,PC,DP,2RC | ||
Filter Wave Length | λs | 0,2.5,8,25μm | |
λc | 0.08,0.25,0.8,2.5,8mm | ||
λf | 0.8,2.5,8,25mm | ||
Evaluation Length | sampling length has standard mode and custom mode | ||
Measurement and Return Speed | 0.05mm/s,0.10mm/s,0.50mm/s,1.00mm/s,2.00mm/s | ||
Sensor | Range | ±1000μm | |
Stylus | 5μmR diamond 90° | ||
Contact force | 0.4~0.75mN | ||
Display Part | 10-inch color IPS touch screen | ||
Data Output | TF card/U disk/WIFI printing/PDF file | ||
Power Supply | AC220V±10% Built-in rechargeable battery (AC adapter charging) 8 hours charging time | ||
Items | Qty | |
Standard Configurations | Host Actuator | 1 |
Sensor | 1 | |
10 inch Pad Operator | 1 | |
Host charger | 1 | |
Pad charger | 1 | |
Standard stylus | 1 | |
Roughness standard test block | 1 | |
Product certificate | 1 | |
Product manual | 1 | |
Warranty card | 1 | |
Data communication line | 1 | |
Host waterproof box | 1 | |
Random tools | Hex Key(2.5mm) |
