Features
●This machine is widely used in building materials, aerospace, machinery manufacturing, wire and cable, rubber and plastic, textile, wood and other industries of material inspection and analysis, is scientific research institutions, colleges and universities, industrial and mining enterprises, technical supervision, commodity inspection arbitration and other departments of the ideal test equipment.
●GB/T16491-1996 Electronic universal testing machine
●The machine operation software covers a total of 200 GB, ISO, ASTM and other standards, including ISO34, ISO 37, ISO 178, ISO 527 proposed by customers
●Speed control system adopts stepper motor and reducer, stable and reliable performance, with over current, over voltage, overload protection devices. The speed control range can reach 0.1 ~ 500mm/min. And has automatic return function.
●Transmission part adopts arc synchronous tooth belt, precision screw pair transmission, smooth transmission, low noise, high transmission efficiency.
●Ensure the concentricity of the test, on the other hand, eliminate the influence of irregular samples on the sensor.
| Quantity: | |
|---|---|
Product Description
Technical Parameter
Model | MS-5E |
Max. Capacity(kN) | 5000N |
Measuring range | 2%—100%FS |
Accuracy | Better than ±1% |
Beam Displacement Measurement | The resolution is 0.01mm |
The Exact Degree of Deformation | Better than ±1% |
Speed Range | 0.1-500mm/min |
Test Space | 600mm |
Host Form | Single-column structure |
Weight | 100Kg |
Working Environment | Room temperature ~ 45℃ Humidity 20% ~ 80% |
Packing List
●Testing machine
●High precision stepper motor
●Deceleration system
●Load sensor
●Precision screw
●Digital control system
●Stretch attachment
●Technical document
